Microhard Systems IPN4GB - Specifications

© Microhard Systems Inc. 11
IPn4G IPn4Gb
4G LTE B4/B17 (1700/2100/700 MHz)
Global Fallback to:
HSPA+/UMTS 850/AWS/1900/2100 MHz
GPRS 850/900/1800/1900 MHz
LTE FDD (Bands 1-5,7,8,13,17,18,19,20)
UMTS | DC-HSPA+ (Bands 1,2,4,5,8)
GSM | GPRS | EDGE (Bands 2,3,5,8)
3GPP Protocol Stack Release 9
4G LTE
Up to 100 Mbps downlink
Up to 50 Mbps uplink
LTE: DL 100 Mbps, UL 50 Mbps
HSPA+: DL 21 Mbps, UL 5.7 Mbps
WCDMA: DL/UL 384 kbps
EDGE Class 33: DL/UL 236.8 kbps
GPRS Class 33: DL/UL 85.6kbps
1.0 Overview
1.2 Specifications
For detailed specifications, please see the specification sheets available on the Microhard web-
site @ http:///www.microhardcorp.com for your specific model.
Electrical/General
Cellular:
Supported Bands:
Data Features:
SIM Card: 1.8 / 3.0 V
WiFi:
Frequency: 2.4 GHz
Spread Method: (CCK) QPSK/BPSK
(OFDM) BPSK, QPSK, QAM16, QAM32, QAM64
Data Rates: 802.11b/g
TX Power: Adjustable / Up to 30dBm
Data Encryption: WEP, WPA(PSK), WPA2(PSK), WPA+WPA2 (PSK)
(Subject to Export Restrictions)
General:
Input Voltage: 9 - 30 VDC
Power over Ethernet: Passive PoE on Ethernet Port
Current Consumption:
(@12VDC & 20dB WiFi)
Serial Baud Rate: 300bps to 921kbps
Ethernet: 10/100 BaseT, Auto - MDI/X, IEEE 802.3
Cellular WiFi Idle (mA) Typical (mA)
On On 350 390
On Off 280 320
Off On 270 320
Table 1-2-1: IPn4G Current Consumption
