MC-20
User Manual / Pneumatic, Electrical and Foot Pedal Connections
15/37
1. The foot pedal has a special grove that will correlate to the grove in the port on the
machine.
Connecting the Foot Pedal
1. The port is located on the right hand side of the machine, towards the rear.
2. Slide the connector into the port and secure with the metal ring. Simply screw it on
clockwise.
