MC-20
User Manual / Installing Dies and Adapters with Dies
19/37
1. Take the upper die which will have a 1/4 inch threaded stem and screw it up
into the installed adapter.
3. Slide the upper die adapter up into the mill ensuring that the flattened
portioned is aligned with one of the two tension screws.
4. Use an Allen wrench to tightly secure the adapter.
