Chapter 2 System Components
2-2 MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
Hardware Components and Accessories
The table below lists MicroHAWK Smart Camera hardware components and the table on
the next page lists the accessories. The reference numbers shown on configuration drawings
later in this section refer to these tables.
Item Part Number Description
1 7ABX-YZZZ-LPPP MicroHAWK MV-20, MicroHAWK MV-30, or MicroHAWK MV-40
2 61-9000034-01 Cable, USB A to Micro B, 6 ft., MV-20
3 61-9000045-01 Cable, USB A to Micro B, 3 ft., MV-20
4 61-9000043-01 Cable, DB15 to BUS Power USB Type A, MV-30
5 98-9000048-01
Kit, Cable, DB15 to Ext. Power/RS-232 with Power Supply, MV-30 – includes
97-9000006-01 and 61-9000037-01
6 97-9000006-01 Power Supply, 5V – for use with cables 61-9000037-01 and 61-9000038-01
7 61-9000037-01 Cable, DB15 to Ext. Power/RS-232, MV-30
8 98-9000049-01
Kit, Cable, DB15 to Ext. Power/USB with Power Supply, MV-30 – includes
97-9000006-01 and 61-9000038-01
9 61-9000038-01 Cable, DB15 to Ext. Power/USB, MV-30
10 98-9000050-01
Kit, Cable, DB15 to Ext. Power/USB, I/O with Power Supply, MV-30 – includes
97-000011-02 and 61-9000039-01
11 97-000011-02 Power Supply, 100-240VAC, +5VDC, 2-Pin U.S./Euro Plug
12 61-9000039-01 Cable, DB15 to Ext. Power/USB, I/O, MV-30
13 97-000012-02 Power Supply, 100-240VAC, +24VDC, TRK 3-Pin, U.S./Euro Plug
14 99-000018-01 IB-131 Interface Box
15 FIS-0001-0035G Converter, IC-332, 24V/5V, Opto I/O – for use with IB-131
16 61-3000026-03 Cable, Communication, DB25 Plug to DB9 Socket, 6 ft.
17 99-000019-01 Photo Sensor, Visible, NPN, Light On, 5VDC
18 61-9000102-01 Cable, DB15 to USB/RS-232, Triggered, MV-30
19 97-000012-01 Power Supply, 100-240VAC, +24VDC, M12 12-Pin Socket
20 98-000103-02 QX-1 Interface Device
21 61-000162-02 Cordset, Common, M12 12-Pin Socket (Screw-On) to M12 12-Pin Plug
22 61-000160-03 Cordset, Host, Ethernet, M12 8-Pin Plug (Screw-On) to RJ45, 1 m.
23 99-000020-01 Photo Sensor, M12 4-Pin Plug, NPN, Dark Off, 2 m.
24 99-000020-02 Photo Sensor, M12 4-Pin Plug, NPN, Dark On, 2 m.
25 61-9000054-01 Cable, M12 12-Pin Socket to 9-Pin Socket and M12 Plug
26 61-9000088-01 Cable, M12 12-Pin Socket to USB Keyboard Wedge and M12 Plug
Upgrade to Visionscape
98-000217-01
Upgrade from AutoVISION to full Visionscape functionality
Mounting Options
98-9000034-01
MicroHAWK MV-20-to-MINI Hawk Adapter Plate Kit
Documentation
37-000010-01
Microscan Tools Drive (Software, documentation, links to Microscan website)
