Illumination
Optics and Lighting
4
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide 4-5
Illumination
Inner LEDs: 4 white, 4 red (625 nm nominal)
Outer LEDs: 8 high-output white or red (617 nm nominal)
Note: MV-20 only has inner LEDs. MV-30 and MV-40 have both inner and outer LEDs.
Options are available for IR and blue outer LEDs.
LED Modules
Description Left P/N Right P/N LED P/N Wavelength
Expansion, Red 43-9500055-01 43-9500056-01 LA E65F-CAEB-24-1 617 nm
Expansion, White 43-9500055-02 43-9500056-02 NFSW036BLT b3-b6/P9-P12 N/A
Expansion, IR 43-9500055-03 43-9500056-03 SFH 4259S 850 nm
Expansion, Blue 43-9500055-04 43-9500056-04 LB E63C-T2V2-35-34 469 nm
