MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide vii
Contents
PREFACE Welcome ix
Purpose of This Manual ix
Manual Conventions ix
CHAPTER 1 Introduction 1-1
Product Summary 1-2
Features and Benefits 1-2
Applications 1-3
Package Contents 1-3
MicroHAWK MV-20, MV-30, and MV-40 Smart Camera Models 1-4
MicroHAWK MV Part Number Structure 1-6
CHAPTER 2 System Components 2-1
Hardware Components and Accessories 2-2
Label Information 2-4
Mechanical Dimensions 2-5
Cabling Configurations 2-12
Mounting the Camera 2-19
I/O Wiring 2-20
Grounding and Power 2-30
I/O Filtering and Debounce 2-32
Camera Definition File Example 2-33
Status Indicators 2-34
