Chapter 4 Optics and Lighting
4-2 MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
Optics
The monochrome and color versions of the MicroHAWK MV-20, MV-30, and MV-40 have a
built-in CMOS sensor, available in Standard Density or High Density optics.
MV-20 Fixed Focus
MV-20 FOV Chart Fixed Focus Lens Type
Camera-to-Part
Distance
SD - FOV (mm) HD - FOV (mm) UHD - FOV (mm)
mm inch Width Height Width Height Width Height
WVGA
50 1.97 49 31 34 22 15 10
64 2.52 61 39 42 27 19 12
1024.02946065412919
190 7.48 170 109 118 75 53 34
300 11.81 265 169 184 118 83 53
400 15.75 352 225 244 156 110 70
SXGA
50 1.97 52 39 36 27 16 12
64 2.52 65 48 45 34 20 15
102 4.02 100 75 69 52 31 23
190 7.48 181 136 125 94 57 43
300 11.81 282 212 196 147 88 66
400 15.75 375 281 260 195 117 88
QSXGA
50 1.97 49 37 34 26 15 12
64 2.52 62 46 43 32 19 14
1024.02957166493022
190 7.48 173 129 120 89 54 40
300 11.81 270 201 187 140 85 63
400 15.75 358 267 248 185 112 84
