Status Indicators
MV-20
The top of the MicroHAWK MV-20 Smart Camera has an LED that indicates whether or not
the device is powered-on.
Additional User Feedback
• Green Flash – A green flash from the front of the unit indicates a Good Read.
• Blue Targeting Pattern – The blue targeting pattern from the front of the unit allows the
user to center an object in the camera’s field of view.
PWR LED
On Power On
Off No Power Applied to Unit
