Chapter 4 Optics and Lighting
4-4 MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
MV-30 and MV-40 Autofocus
Sensor Table
MV-30/40 FOV Chart Autofocus Lens Type
Camera-to-Part
Distance
SD - FOV (mm) HD - FOV (mm) UHD - FOV (mm)
(mm) (inch) Width Height Width Height Width Height
WVGA
50 1.97 46 29 33 21 15 10
64 2.52 57 37 42 27 19 12
102 4.02 88 56 64 41 30 19
190 7.48 159 101 115 74 54 34
300 11.81 247 158 180 115 83 53
400 15.75 328 209 238 152 111 71
SXGA
50 1.97 49 37 36 27 16 12
64 2.52 61 46 44 33 21 15
102 4.02 93 70 68 51 32 24
190 7.48 169 127 123 92 57 43
300 11.81 263 197 191 144 89 67
400 15.75 349 262 254 190 118 88
QSXGA
50 1.97 47 35 34 25 16 12
64 2.52 58 43 42 32 20 15
102 4.02 89 67 65 48 30 22
190 7.48 161 120 117 87 54 41
300 11.81 252 187 183 136 85 63
400 15.75 334 249 243 181 113 84
Pixels (H x V) Shutter
Frames per Second
(Standard / High)
WVGA 752 x 480, 0.3 MP, Mono Global 10 fps / 60 fps
SXGA 1280 x 960, 1.2 MP, Mono Global 10 fps / 42 fps
QSXGA 2592 x 1944, 5 MP, Color Rolling 5 fps
