Chapter 2 System Components
2-14 MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide
MicroHAWK MV-30 with DB15 to Ext. Power/RS-232
MicroHAWK MV-30 with DB15 to Ext. Power/USB, I/O
1
1
Power
Supply
To host
Integrated
Corner-Exit
Cable
6
7
To Trigger
Accessory
USB Cable
to Host
Integrated
Corner-Exit
Cable
To
Power
Supply
12
MicroHAWK MV-30 with DB15 to USB/RS-232, Triggered
1
18
To Host
To Trigger
To Power Supply
To Host
(RS-232)
Integrated
Corner-Exit
Cable
Accessory
USB Cable
to Host
