1.
2.
User Output
to SA.22c
Response to
Host
Command Name and Description
o N (example of
command and data to
give 10 MHz for a
VCXO of 60 MHz is:
)o3
To be specified The default frequency output is 10 MHz .
1
p To be specified Displays control register.
q Hex data to set or
reset bits in the control
register
immediately follows
the command
(Example: )q3A
To be specified Set control register
Allows enabling or disabling of outputs.
t SAVE command
Example: to SAVE
changes:
5987717<cr>
To be specified Saves all changes made .
2
w To be specified Displays health monitor data.
Contact the manufacturer for information about other frequencies.
If the t command is not used, unit defaults to factory settings at next power up.
Table 11 • Factory Mode Commands
User Output to SA.22c Response to Host Command Name and
Description
Command Data
a a> Goes to administration mode.
i Outputs 7 lines of banner (same as power-up information) Displays unit Information.
r Run
mode
Enter run mode. FC mode is disabled (enabled) Goes to run mode.
Note: Run mode and admin mode allow the loading of new code, updates, or reconfiguring defaults in
the field. It is not a normal operating mode.
Table 12 • SA.22c Administrative Mode Commands
User Output to SA.22c Response to Host Command Name and Description
Command Data
a Outputs 7 lines of banner
(same as power-up
information)
Unit information same as the i command in factory
mode and run mode.
b File from
Microsemi (self-
burning)
To be specified Operating this command without valid file will not
overwrite the existing data stored in flash memory.
x Run mode x f> Exit administrative mode to factory mode.
y Y asks are you sure? Soft reset. Restarts processor.
z Z asks are you sure? Puts unit into a mode where it will wake only when
the power is recycled.
Note: Admin mode allows the loading of new code, updates, or reconfiguring defaults in the field. It is
not a normal operating mode.
