53 DIGITAL RACK MIXER M32R User Manual
Display
Main Screen 5" TFT LCD, 800 x 480
Resolution, 262k Colours
Channel LCD Screen 128 x 64 LCD with
RGB Colour Backlight
Main Meter 18 Segment (-45 dB to Clip)
Power
Switch-Mode Power Supply Auto-Ranging 100-240 VAC
(50/60 Hz) ± 10%
Power Consumption 70 W
Physical
Standard Operating 5°C – 40°C (41°F – 104°F)
Temperature Range
Dimensions 478 x 617 x 208 mm
(18.8 x 24.3 x 8.2")
Weight 14.3 kg (31.5 lbs)
* A-weighted figures are typically ~3 dB better
4.2 Appendix B: MIDI Operation
MIDI RX > Scenes
Whenever Program Change messages in the range 1-100 are received on
MIDI CH01, thecorresponding scene of the M32R internal show memory will
be loaded.
This requires the following preconditions:
SETUP / remote
• MIDI In/Out check marks must be set according to the connection on
which MIDI input will be accepted (via physical MIDI connectors on M32
or S16, or via DN32-USB card)
• MIDI In/Out check mark must be set for “Enable MIDI Scene Recall”.
SETUP / global
• When tick mark “Conrm Pop-Ups” / “Scene Load” is active, MIDI scene
recalls will only become active after manual conrmation
• If you prefer activating scenes via MIDI Program Changes immediately,
un-check the “ConrmPop-Ups” / “Scene Load” tick mark.
SHOW CONTROL VIEW / home
• Valid scenes must be stored in the internal M32R show le. It is not
possible to recall emptyscenes
• The scope of changes applied by a MIDI scene recall depends on the
Scene Safes, ParameterSafes and Channel Safes settings, same as with
recalling the scene locally.
MIDI TX > Scenes
Every scene can be assigned one specic MIDI command/event. Each time the
scene is loaded the MIDI command will be sent out once. Possible choices for MIDI
commands/events to be found on Scenes View/MIDI page:
• O > no message will be sent upon scene load
• Program Change > select the MIDI Channel and the Program Number
(using knobs 4/5 at the main display)
• Control Change > select the MIDI Channel, Controller number and
value(using knobs 4-6 at the main display)
• Note > select the MIDI Channel, Note number and velocity(using knobs
4-6 at the maindisplay).
Will send out a Note On command directly followed by the same
Note O command.

Midas M32R Specifications

General

Channels	40
Mix Buses	25
Matrix Buses	8
Digital Signal Processing	40-bit floating point
Type	Digital
EQ Bands	4-band parametric
Talkback	Yes
Sample Rate	48 kHz
Networking	Ethernet
Display	7" TFT
Effects	8 x FX engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
I/O Expansion Slots	1
MIDI I/O	In/Out
Word Clock	Yes
Control	Yes
Inputs	32
