55 DIGITAL RACK MIXER M32R User Manual
MIDI CC (raw) selected and Remote is enabled+active, thegroup section controls
will transmit/receive the following messages:
MIDI RX MIDI Ch Controller Comment
Group 1-8 SELECT 1 Note 64-71 on (127) / o (0), push non-latching
Group 1-8 SOLO 1 CC 32-39 on (127) / o (0), toggle latching
Group 1-8 MUTE 1 CC 40-47 on (127) / o (0), toggle latching
Sends On Fader 1 CC 48 on (127) / o (0), toggle latching
Group DCA 1-8 1 Note 72 on (127) / o (0), push non-latching
BUS 1-8 1 Note 73 on (127) / o (0), push non-latching
BUS 9-16 1 Note 74 on (127) / o (0), push non-latching
MTX 1-6 1 Note 75 on (127) / o (0), push non-latching
GROUP Faders 1 CC0-7 0-127
HUI selected and Remote is enabled+active, then the group fader section and
buttons will emulate the HUI control surface protocol, i.e. for ProTools.
SELECT/SOLO 1-8 buttons will select or solo the corresponding track in the DAW,
in banks of eighttracks
Sends On Fader = enables touch-writing a fader automation on selected track,
trackautomation mode in DAW must be ‘touch’, (latching)
Use the layer buttons to determine the function assigned to
the MUTE 1-8 buttons, the LED displays indicate that function.
• Group DCA 1-8 = allows movement of the bank selection of tracks
in a DAW, (push non-latching)
• BUS 1-8 = allows the setting of DAW tracks to ‘Record Ready’,
(push non-latching)
• BUS 9-16 = enables use of MUTE buttons for track mute in
the DAW, (latching)
• MTX 1-6 = enables use of MUTE buttons for transport controls in
the DAW, (latching).
MACKIE CTRL selected and Remote is enabled+active, then the group fader
section and buttons will emulate the Mackie Control Universal protocol
SELECT/SOLO 1-8 buttons will select or solo the corresponding track in the DAW,
in banks of eighttracks
Sends On Fader = enables touch-writing a fader automation on selected track,
track automation mode in DAW must be ‘touch’ or ‘latch’, (latching)
Use the layer buttons to determine the function assigned to the
MUTE 1-8 buttons, the LED displays indicate that function.
• Group DCA 1-8 = allows movement of the bank selection of tracks in a
DAW, (push non-latching)
• BUS 1-8 = allows the setting of DAW tracks to ‘Record Ready’,
(push non-latching)
• BUS 9-16 = enables use of the MUTE buttons for track mute in
the DAW, (latching)
• MTX 1-6 = enables use of the MUTE buttons for transport controls in
the DAW, (latching).

Midas M32R Specifications

General

Channels	40
Mix Buses	25
Matrix Buses	8
Digital Signal Processing	40-bit floating point
Type	Digital
EQ Bands	4-band parametric
Talkback	Yes
Sample Rate	48 kHz
Networking	Ethernet
Display	7" TFT
Effects	8 x FX engines
Data I/O	Ethernet
Computer Connectivity	USB, Ethernet
I/O Expansion Slots	1
MIDI I/O	In/Out
Word Clock	Yes
Control	Yes
Inputs	32
