ATTITUDE OPERATION
Flight Mode / ATTITUDE OPERATION
REV. F Sept 15, 2015 Manual Number 9017846
5
Image 4
Roll/Bank Scale
Symbolic Airplane
Pitch Scale
Horizon Line
Slip Indicator
The Pitch Scale is depicted as a series of graduations representing
pitch angles every 5°, with every 10° graduation being wider and
numbered. The unit is operable and usable in a continuous and
unlimited pitch range of 360°+.
