SECTION 1
DESCRIPTION
SECTION 1
DESCRIPTION
I. MODEL IDENTIFICATION
The Mideleby Marshall PS520-Series may be used
either as a single oven or stacked for use as a double
or triple ovens.
A single PS520-Series Oven (Figure 1-1) is mounted
on a base pad with legs. A double oven (Figure 1-2)
consists of two, stacked, single ovens. A triple oven
(Figure 1-3) consists of three stacked single ovens.
The lower oven is mounted on a base pad.
On a double or triple oven, the ovens operate indepen-
dently. All ovens use identical controls and compo-
nents. One oven can be cleaned or serviced, while the
others are operating.
Figure 1-1. Single PS520 Oven
Figure 1-2. Double PS520 Oven
Figure 1-3. Triple PS520 Oven
