NOTE
Wiring Diagrams are contained in Section 6 of this manual and are also located inside the
oven at the bottom of the control panel.
This Manual Must Be Kept For Future Reference
PS520 SERIES OVEN SPECIFICATIONS
Conveyor Belt Width 18.00” (457mm)
Heating Zone Length 20.00” (5098mm)
Baking Area Square Feet 2.5 sq ft (.023 sq. m.)
Overall Dimensions
Standard Single Oven w/Legs 42.00” (1067mm) L x
35.21” (894mm) W x
21.72” (786mm) H x
Overall Dimensions
Double Oven 42.00” (1067mm) L x
35.21” (894mm) W x
37.27” (947mm) H x
Overall dimensions
Triple Oven 42.00” (1067mm) L x
35.21” (894mm) W x
52.82” (1342mm) H x
Weight of Single Oven 250 lbs (93.3kg)
Shipping Weight 325 lbs (121.3kg)
Operating Range 8.3 kW/hr
Maximum Operating temperature 550
0
F (287
0
C)
Warm-up Time 20 min.
Belt Speed Limits 1-10 minutes
SERIES PS520 ELECTRICAL SPECIFICATIONS
Main Blower & Control Circuit Phase Frequency Amperage Poles Wires
Elements Voltage Voltage Draw
All Models 208-240V 208-240V 1 Ph 50/60 Hz See Below 2 Pole 3 Wire
(2 hot, 1 grd)
Heater Amperage
Voltage kW Amp
208 8.3 39.9
230 7.6 33.0
240 8.3 34.6
Non-CE 380V 230-240V 1 Ph 50/60 Hz See Below 3 Pole 4 Wire
Heater Amperage (2 hot, 1 neut, 1 grd)
Voltage kW Amp
380 8.3 21.8
Domestic/Non-CE 480V 208-240V 1 Ph 50/60 Hz See Below 3 Pole 4 Wire
Heater Amperage (2 hot, 1 neut, 1 grd)
Voltage kW Amp
480 8.3 17.3
CE Only 380-400V 230-240V 1 Ph 50/60 Hz See Below 2 Pole 3 Wire
Heater Amperage (2 hot, 1 grd)
Voltage kW Amp
380 8.3 21.8
400 8.3 23.0
3 Ph 50/60 Hz See Below 4 Pole 5 Wire
Heater Amperage (3 hot, 1 neut, 1 grd)
Voltage kW L1 L2 L3 N
380 8.3 21.8 21.8 1.2 1.2
400 9.2 23.0 23.0 1.2 1.2
SECTION 1
DESCRIPTION
