- - 13
拆除活性碳：先拆除过滤网，然后两手抓住其中一个活性碳两侧按红箭头松脱的方向旋转，使活
性碳中间锁扣旋转至松脱位置，可取出活性碳，另一活性碳可重复刚才的动作，取出活性碳。
安装活性碳：请同样抓住活性碳两侧，将活性碳贴紧风机组件进风口端面按红箭头相反的方向旋
转到紧固位置，可锁紧活性碳。
Remove charcoal: remove strainer first, then grasp the two sides of one charcoal , rotate in the loose arrow
direction until the lock catch in the middle of charcoal gets loose, then take out
charcoal . The other charcoal can repeat the above movement and take out.
Install charcoal: grasp the two sides of charcoal, then rotate charcoal end surface close to the air inlet of fan
assembly in the arrow direction to fastening position until charcoal is fastened.
6.3 拆卸箱体前板 Dismantle Body Front Plate
工具：十字螺丝刀 Tool: Cross Screwdriver
步骤：塔型烟机和T型烟机均可借助工具拆卸箱体前板，如下图：
Step: The body front plate of tower-type and T-type hood can be dismantled by tool, as below picture
从红色箭头所指处用十字螺丝刀卸掉两颗螺钉，然后拽着箱体前板沿蓝色箭头方向可取出箱体前板。
At the position indicated by the red arrow, use the cross screwdriver to remove two screws, then pull out the
To Next Page
