6.7 拆卸电源线 Dismantle Power Cord
工具：H头螺丝刀、专用线扣钳
Tool: H-Screwdriver, Special Clasp Forceps
如电源线采用压线块固定，则按上图步骤打开接线盒盖，用H头螺丝刀将压线块拆卸下来，拔出
电源线端子，如图：
If use pressing block to fix power cord, open junction box cover as the above step, remove the pressing
block with H-screwdriver, pull out power cord terminal.
Fan assembly dismantling
completed
Pressing block and
H-screw
