注意！Caution
1. 检查故障前请先检查电源线接地；
Check the power cord grounding before checking the fault.
2. 注意高压电路部分。
Pay attention to the high voltage circuit.
7.2 主要部件维修与检测 Main Components Maintenance and Detection
7.2.1 开关组件更换 Switch Assembly Replacement
工具：十字螺丝刀 Tool: Cross Screwdriver
操作步骤：Operation Step:
1. 将烟机放在一个平整的平台上，断开电源；
Put the range hood on a flat platform, switch the power off;
2. 按照 6.5 开关拆卸步骤方法将损坏的开关组件拆卸下来；
Dismantle the damaged switch assembly according to switch dismantling step in 6.5;
3.准备好替换的完好的开关组件，按照 6.5 相反的步骤顺序将开关组件安装好。
Prepare the intact switch assembly for replacement; install the switch assembly according to the contrary
step sequence of 6.5.
7.2.2 接线板更换 Terminal Block Replacement
工具：十字螺丝刀 Tool: Cross Screwdriver
操作步骤：Operation Step:
1. 将烟机放在一个平整的平台上，断开电源；
Put the range hood on a flat platform, switch the power off;
2. 按照 6.8 接线板拆卸步骤方法将损坏的接线板拆卸下来；
Dismantle the damaged terminal block according to terminal block dismantling step in 6.8;
3.准备好替换的完好的接线板，按照 6.8 相反的步骤顺序将接线板安装好。
Prepare the intact terminal block for replacement; install the terminal block according to the contrary step
sequence of 6.8
7.2.3 风机组件更换 Fan Assembly Replacement
工具：十字螺丝刀 Tool: Cross Screwdriver
操作步骤：Operation Step:
1. 按照 6.6 风机组件拆卸步骤方法将损坏的风机组件拆卸下来；
Dismantle the damaged fan assembly according to fan assembly dismantling step in 6.6;
2. 准备好替换的完好的风机组件，按照 6.6 相反的步骤顺序将风机组件安装好。注意罩极电机和电容
电机的拆卸安装区别。
Prepare the intact fan assembly for replacement; install the fan assembly according to the contrary step
sequence of 6.6. Pay attention to the dismantling and installation difference of shaded-pole motor and
capacitor motor.
