Midea l712wmb16 - Undo the Lower Panel; Undo the Door Lock; Undo the Front Panel

P.22
Operation step Picture
4.UNPACKING WAYS OF MAIN PARTS
4 the lower panel
Loosen the screws fit on
the lower panel.
Pinch the clasp, and push
Undo
①
②
5 Undo the door lock
open the door of washing
machine.
Take the outer gasket
clamp to the drum.
①
②
Push door lock outward
direction.
Take out the door lock
and draw out the plug; pay
attention to of the position
the plug so as connectnot to
a wrong circuit next time.
③
④
6 Undo the front plate
Undo the door lock
(methods as followed).
Remove the lower
cover(methods as
followed).
①
②
Use coin or screwdriver
③
to open the filter cover.
③
④
Undo the screws in the
front plate.
Put the front plate up to
the plate clasp of the front
away from loading holder, the
and then take off the front plate.
it out.
