Midea l712wmb16 - Undo the PCB Panel; Undo the Detergent Box; Undo the Inlet Valve

P.24
4.UNPACKING WAYS OF MAIN PARTS
Operation step Picture
10 the detergent Undo
box
① the top cover Undo
and the control panel
( ).methods as followed
② Release the hose clamp
and pull out the inlet hose.
③ Release the hose clamp
and pull out the detergent
box hose, and then take
out the detergent box.
11 the inlet valveUndo
① Remove the top cover
( ).methods as followed
② Undo 2 screws between
cabinet and inlet valve.
9 Undo the PCB panel
Undo the top cover
and control panel(methods
as followed).
