P.23
4.UNPACKING WAYS OF MAIN PARTS
Operation step Picture
③ Undo five screws in
the front plate.
④ Put the front plate up
to the clasp of the front
plate away from the
loading holder, and then
take off the front plate.
8 Undo the gasket
① Undo the top cover,
control panel, lower cover,
machine door and the front
plate(methods as
followed).
② Remove the outer
gasket clamp between the
door seal and the front
plate.
③ Loosen the inner gasket
clamp between the door
seal and the front of the
outer tub, and take out the
gasket.
7Undo the facade
counterweight
Undo the front plate
(methods as followed).
①
Remove screws pull
②
out the facade
counterweight.
To Next Page
