Page 13
NOTICE
When the continuous draining feature is not being used,
remove the drain hose from the outlet, and dry the water
in the continuous drain hose outlet.
2. Continuous draining
• Water can be automatically emptied into a floor drain
by attaching the unit with a water hose (Id
Ø 5/16”,
not included) with a female threaded end (ID: M = 1”,
not included).
• Remove the plastic cover from the back drain outlet
of the unit and set aside, then insert the drain hose
through the drain outlet of the unit and lead the
drain hose to the floor drain or a suitable drainage
facility. (See Fig. 8 and Fig. 9)
• When you remove the plastic cover, if there is some
water in the back drain outlet of the unit you must
dry it. Make sure the hose is secure so there are
no leaks and the end of the hose is level or sloping
downwards to let the water flow.
• Direct the hose toward the drain, making sure that
there are no kinks that will stop the water flowing.
• Select the desired humidity setting and fan speed on
the unit for continuous draining to start.
Fig. 9
Fig. 8
Remove the
plastic cover
rotating counter-clockwise
Drain hose
Removing the Collected Water (cont.)
Fig. 10
3. Pump draining (Pump models only)
Water can be automatically emptied into a floor drain or
a suitable drainage facility by attaching the pump drain
out with a pump drain hose (Ø od = 1/4”, supplied).
• Remove the continuous drain hose from the unit and
install the plastic cover to the continuous drain hose
outlet of the unit by clockwise rotation. (See Fig. 10)
• Insert the pump drain hose into the pump drain hose
outlet for at least 15 mm (See Fig. 10), then lead the
water hose to the floor drain or a suitable drainage
facility.
• Press the pump pad on the unit to activate the
pump operation. When the bucket is full the pump
starts to work.
Pump drain
hose
Pump drain
hose outlet
Reinstall the
plastic cover
Operating
Instructions
