Safety
Precautions
Installation
Requirements
Installation
Instructions
DRAIN CONNECTION HEIGHT
The drain connection method depends on the height of the drain hose
connection.
IMPORT
ANT: Failure to connect the drain hose at a height of 18" with air
gap (not provided) OR to create a drain loop with a minimum height of
32" (81.3 cm) will result in improper draining of the dishwasher.
WATER SUPPLY REQUIREMENTS
• Water pressure from the hot water supply line must be between
20-120 psi (138-862 kPa).
• Water heater that is adjusted to a water temperature of 120°F to 150°F
(49°C to 65.5°C).
• A " min. diameter copper tubing water line extending at least 24"
(61 cm) from the rear wall, and routed to connect to the front left-hand
side of the dishwasher.
• A hand shut-off valve in an accessible location, such as under the sink
(optional, but strongly recommended).
ELECTRICAL REQUIREMENTS
WARNING
Electrical Shock Hazard
•
Installation and service must be performed b
y a
qualified in taller or service agency.
•
Always disconnect the pow
er before servicing this unit.
•
This appliance must be properly grounded.
•
Failure to do so could result in dea
th, fi e, or electrical
shock.
IMPORTANT:
•
The dishwasher must be supplied with 120 volt, 60 Hz., and c
onnected
to a dedicated, properly grounded branch circuit, protected by a 15 or
20 ampere circuit breaker or time delay fuse.
•
Maximum of two field wiring supply onductors (12 AWG Maximum)
plus one gr
ounding conductor are permitted in the terminal box.
•
Use Only copper wire.
•
Wiring must be 2-wire with ground.
•
Use a UL Listed/CSA Appro
ved metallic strain relief.
•
Be sure that the electrical connection and wire size ar
e adequate and
in conformance with the National Electrical Code, ANSI/NFPA No.
70-latest edition and all local codes and ordinances.
•
If the electrical supply does not meet the above requirements, call a
licensed, qualified electrician be
ore proceeding.
