17
Safety
Precautions
Installation
Requirements
Installation
Instructions
WHEN THERE ARE NO EXIS
TING UTILITY
C
ONNECTIONS
PREPARE TO CONNECT POWER SUPPLY
Connect to the Power Supply using one of tw
o Methods: Direct Wire
Cable (Method 1) or Power Cord (Method 2). Follow the instructions
specific o your installation.
WARNING
Electrical Shock Hazard
•
Disconnect electrical power at the fuse box or cir
cuit
breaker box before installing dishwasher.
•
Failure to do so can result in death or electrical shock.
Method 1 - Dir
ect Wire
1. Drill a
" (1.9 cm) hole into the right-hand cabinet, or the right-hand
side of the back wall or floor of the opening. See ollowing graphic f
or
preferred and optional locations.
NOTE: Wiring the dishwasher will be easier if the wire is routed into the
opening from the right-hand side.
ba
a
Preferred
Locations
b
Optional Locations
2. Smooth or cover r
ough edges of the hole that the wiring will pass
through.
Wood Cabinet - Sand edge of hole until smooth.
Metal Cabinet - Cover edge of hole with grommet (not provided).
3. Route the cable from the power supply through the hole (cable must
extend to the front, right-hand side of the opening). Extend cable to 6"
(15.2 cm) in front of unit and tape the cable to the floor o keep it from
moving when dishwasher is moved into the cabinet opening.
6" (15.2 cm)
direct
wire
3" to
(7.6 cm to
cm)
tape
NOTE: You can
tape the wire to the floor to secure it while dishwasher is
moved into place.
"
4
000
10.8
