31
OPTION 2 - Securing Dishwasher to Adjacent Cabinets
1. With the help of two or more people, stand the dishwasher upright.
2. Insert the top-mounting clips into the upper frame. Secure the mounting
clips to the edge hole of the upper frame with provide # 6 X 1/2 IN screw.
3. Secure the top-mounting clips to the uderside of the wood countertop with
provide # 8 x 3/4 IN screw.
NOTE: The top mo
unting clips have scored lines, to allow a section of the clip
can be removed, if necessary, to fit the depth of the cabinet
# 6 x 1/2 IN
Top-mounting Clip
Scored lines
# 8 x 3/4 IN
Top-mounting Clip
1. Remove the plastic tub caps from the inside of the dishwasher tub.
2. Drive # 8 X 1-1/4 IN screw through the hole in the side of the
dishwasher into the cabinet frame(Repeat for each side).
3. Reinsert the plastic tub caps.
Installation to Adjacent Cabinets
There are 2 options for securing the dishwasher. If the countertop is made of
wood or a material that can safely be drilled into, you can use option 1 or option
2 below. If the countertop is granite, marble, or a material that cannot be
drilled,use option 2 below.
Option 1 - Securing Dishwasher to Countertop
To enable you to secure the dishwasher to the countertop, install two mounting
clips to the top of the dishwasher.
To Next Page
