1. Controller
1.1 R05/BGE
The R05/BGE wireless remote controller is for Four-way cassette type and the Ceiling& floor type.
1
Mo de s et ting
5
ON/OFF
7
Horiz swing
9
Tim e settin g
6
Air direction setting
8
Vert. swing
11
Ti me OFF
10
Time ON
Ad jus t
2
Fan speed se ttin g
4
Adjus t
1
3
Co ol /heat
Lock
Reset
15
13
12
14
Confirm button
16
Eco no mic operation
TIME ON
TI ME OF F
CLOCK
SWIN G
A I R D I RE CTI ON
OK
ECO
SW I N G
MOD E
FAN
S P EED
M
AUTO
COOL
DRY
HEAT
FAN
TE M P
SET
SET
Visual photo
1.3 General Function for wireless remote controller:
Model and Specification
Model R05/BGE
Rated voltage 3.0V(2pieces of LR03 7＃ batteries)
Min voltage for sending signal of CPU 2.4V
Effective receiving distance 8m~11m
Operation condition -5~60
