 Indoor Unit Disassembly 5 
Procedure Illustration
5) Remove 1 screw and then remove the
electrical cover(see CJ_MA_005).
6) Disconnect the connector for display
board(see CJ_MA_006) .
7) Remove 1 screw and overturn the
display panel to remove the display
board.(see CJ_MA_006).
CJ_MA_005
CJ_MA_006
Note: This section is for reference only. Actual unit appearance may vary.
