Outdoor Unit Disassembly 32
Procedure Illustration
6) Remove the screws of the right panel
and then remove the right panel
(5 screws) (see CJ_X101_005).
CJ_X101_005
Note: This section is for reference only. Actual unit appearance may vary.
