Service Manual_2020-V1.0
21
7. Dismantling of parts
7.1 Parts on the door
Door seal is installed into door liner groove.
1)Open the refrigerator door;
2)Take the door seal out of door liner;
While squeezing it inward, lift up the door tray and take it
out from door liner.
After removing the door, remove the fixing screws at the
position shown in the figure, remove the door sleeve pipe
and stopper, and complete the stopper replacement.
7.2 Parts inside the refrigerator
Lift up the division plate with a proper force and pull it out
towards yourself;
To Next Page
