Service Manual_2020-V1.0
38
Press the “Turbo Freeze” button for three seconds and the“ON” icon will illuminate. The
temperature of freezing chamber is set to -24℃ (-11℉). Automatically exit for up to 8 hours.
9.3.2 Celsius / Fahrenheit temperature switch
Press the“+”and“-”button for three seconds to switch, and the ℃ and ℉ icon will
illuminate.
9.3.3 Locking and unlocking
In unlocking state, keep pressing the “Unlock” button for 3 seconds to lock, and the locking beeping
will be rang.
In locking state, keep pressing the “Unlock” button for 3 seconds to unlock, and the unlocking
beeping will be rang.
The refrigerator enters into locking state automatically 30 seconds after no button operation.
Except for the door open alarm and failure alarm can be carried out in the locking state, others
button operations shall be conducted in unlocking state.
9.3.4 High temperature alarm
When Tf ≥ -8 °C and duration ≥ 36 hours. (< -8 °C and the duration is cleared) (It must be detected
once that the temperature of frozen sensor is lower than -15 °C for judgement), then enter the
over-temperature alarm, the high-temperature alarm indicator lights up; the buzzer sounds for 10
seconds at 1Hz frequency and then sounds for 10 seconds every 30 minutes.
The alarm is released when Tf < -12 °C. Operate any key to cancel the buzzer alarm.
9.4 Defrosting function
◆ Defrosting theory:
The defrosting of evaporator is realized by the heating of heater, following the temperature rise, the frost
on evaporator becomes water, and the water flow into the evaporating pan via the draining system, the
water in evaporating pan evaporate away finally
◆ Defrosting steps:
Compressor shutdown--- the freezer fan motor closed, the heater start working ---the heater stop when
the temperature rise to setting--- after 7 minutes, the compressor will start--- after 8 minutes, the fan
motor will start work
◆ Meet one of the following conditions , defrost heating exit:
1) When the defrosting sensor has no fault, the measured temperature Tfd ≥ the set temperature 12℃
(54℉) which frozen defrost heating exit and the set temperature 7℃(45℉) which refrigerat defrost
heating exit
2) When the defrosting sensor has no fault, the defrosting time is ≥ 60 minutes
3) When the defrosting sensor is faulty , the heater will stop after work 20 minutes
9.5 Open door alarm
When the door is opened, the door opening indicator light is on, and when the door is closed, the door
opening indicator light goes out;
At any time, when the door opening time of the freezing chamber is more than 5 minutes, it will enter the
door opening alarm, and the door opening alarm indicator light flashes according to 500ms opening and
