Service Manual_2020-V1.0
23
7.5 Air duct components in freezing chamber and fan motor
Air duct components in freezing chamber
All accessories in the freezing chamber should be
dismantled before removing the air duct components.
1）Remove 1 screws on the cover plate of the freezing air
duct using a cross screwdriver
2）Open the cover plate, pull out the terminal and take out
the lower air duct cover plate.
3）hold the upper cover from the bottom, pull out the
upper cover
4)Take out the freezing air duct assembly.
To Next Page
