Midea MSC-07CRN1 User Manual

Service manual
16
8. Installation details
8.1 Wrench torque sheet for installation
Outside diameter Torque
mm inch Kg.m
φ 6.35
1/4 1.8
φ 9.52
3/8 4.2
φ 12.7
1/2 5.5
8.2 Connecting the cables
The power cord of connect should be selected according to the following specifications sheet.
Grade
Unit 7K 9K 12K
18K
mm
2
1.0 1.0 1.5 2.5
8.3 Pipe length and the elevation
Pipe size
Capacity
Btu/h
GAS LIQUID
Standard
length(m)
Max.
ElevationB (m)
Max. Pipe
lengthA (m)
Additional
refrigerant(g/m)
07k~09K
3/8’’ ( φ
9.52)
1/4’’ ( φ
6.35)
5 5 10 30
12K
1/2’’ ( φ
12.7)
1/4’’ ( φ
6.35)
5 5 10 30
18K
1/2’’ ( φ
12.7)
1/4’’ ( φ
6.35)
5 8 15 30
