9.4 MSC-09HRN1
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions
Pressure 25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
21ºC D15ºC W Pressure( kg/cm
2
)
7.8 8.1 8.4 9.0 9.3 10.0
24ºC D17ºC W Pressure( kg/cm
2
)
7.9 8.2 8.7 9.0 9.5 10.1
27ºC D19ºC W Pressure( kg/cm
2
)
8.0 8.5 9.2 9.9 10.2
10.8
32ºC D23ºC W Pressure( kg/cm
2
)
8.8 9.1 9.2 10.0
10.5
11.2
Heating mode OUTDOOR CONDITIONS
Indoor Conditions
Pressure
12ºC D
11ºC W
7ºC D
6ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
-7ºC D
-9ºC W
-15ºC D
-xºC W
15ºC Pressure( kg/cm
2
)
26.5
25.0
22.0
21.5
20.5
/
18ºC Pressure( kg/cm
2
)
27.0
26.0
23.5
22.5
20.8
/
20ºC Pressure( kg/cm
2
)
27.5
26.5
25.0
23.0
21.0
/
22ºC Pressure( kg/cm
2
)
28.5
27.0
25.5
23.9
21.5
/
9.5 MSC-12CRN1
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions
Pressure 25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
21ºC D15ºC W Pressure( kg/cm
2
)
8.4 8.5 8.8 8.9 9.4 9.9
24ºC D17ºC W Pressure( kg/cm
2
)
8.6 8.8 9.2 9.4 10.0
10.4
27ºC D19ºC W Pressure( kg/cm
2
)
8.8 9.2 9.4 9.8 10.3
10.9
32ºC D23ºC W Pressure( kg/cm
2
)
9.2 9.6 9.9 10.4
10.8
11.2
9.6 MSC-12HRN1
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions
Pressure 25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
21ºC D15ºC W Pressure( kg/cm
2
)
8.4 8.5 8.8 8.9 9.4 9.9
24ºC D17ºC W Pressure( kg/cm
2
)
8.6 8.8 9.2 9.4 10.0
10.4
27ºC D19ºC W Pressure( kg/cm
2
)
8.8 9.2 9.4 9.8 10.3
10.9
32ºC D23ºC W Pressure( kg/cm
2
)
9.2 9.6 9.9 10.4
10.8
11.2
Heating mode OUTDOOR CONDITIONS
Indoor Conditions
Pressure
12ºC D
11ºC W
7ºC
D
6ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
-7ºC D
-9ºC W
-15ºC D
-xºC W
15ºC Pressure( kg/cm
2
)
27.4
25.9
22.2
21.4
20.0
/
18ºC Pressure( kg/cm
2
)
29.8
27.2
23.8
22.0
21.1
/
20ºC Pressure( kg/cm
2
)
30.2
29.1
24.2
23.6
22.1
/
22ºC Pressure( kg/cm
2
)
32.4
30.1
25.4
24.0
22.7
/
