Service manual
30
Heating mode OUTDOOR CONDITIONS
Indoor Conditions
Pressure
12ºC D
11ºC W
7ºC D
6ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
-7ºC D
-9ºC W
-15ºC D
-xºC W
15ºC Pressure( kg/cm
2
)
13.2 12.5 11.0 10.7 10.2 /
18ºC Pressure( kg/cm
2
)
13.5 13.0 11.7 11.2 10.4 /
20ºC Pressure( kg/cm
2
)
13.7 13.2 12.5 11.5 10.5 /
22ºC Pressure( kg/cm
2
)
14.2 13.5 12.7 11.9 10.7 /
9.5 MSH-12CR
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions
Pressure 25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
21ºC D15ºC W Pressure( kg/cm
2
)
4.1 4.2 4.4 4.4 4.7 4.9
24ºC D17ºC W Pressure( kg/cm
2
)
4.3 4.4 4.6 4.7 5.0 5.2
27ºC D19ºC W Pressure( kg/cm
2
)
4.4 4.6 4.7 4.9 5.1 5.4
32ºC D23ºC W Pressure( kg/cm
2
)
4.6 4.8 4.9 5.2 5.4 5.6
9.6 MSH-12HR
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions
Pressure 25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
21ºC D15ºC W Pressure( kg/cm
2
)
4.1 4.2 4.4 4.4 4.7 4.9
24ºC D17ºC W Pressure( kg/cm
2
)
4.3 4.4 4.6 4.7 5.0 5.2
27ºC D19ºC W Pressure( kg/cm
2
)
4.4 4.6 4.7 4.9 5.1 5.4
32ºC D23ºC W Pressure( kg/cm
2
)
4.6 4.8 4.9 5.2 5.4 5.6
Heating mode OUTDOOR CONDITIONS
Indoor Conditions
Pressure
12ºC D
11ºC W
7ºC D
6ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
-7ºC D
-9ºC W
-15ºC D
-xºC W
15ºC Pressure( kg/cm
2
)
13.7 12.9 11.1 10.7 10.0 /
18ºC Pressure( kg/cm
2
)
14.9 13.6 11.9 11.0 10.5 /
20ºC Pressure( kg/cm
2
)
15.1 14.5 12.1 11.8 11.1 /
22ºC Pressure( kg/cm
2
)
16.2 15.0 12.7 12.0 11.3 /
9.7 MSH-16CR
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions
Pressure 25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
21ºC D15ºC W Pressure( kg/cm
2
)
4.2 4.3 4.4 4.5 4.7 4.9
24ºC D17ºC W Pressure( kg/cm
2
)
4.3 4.5 4.6 4.7 5.0 5.2
27ºC D19ºC W Pressure( kg/cm
2
)
4.4 4.6 4.7 4.9 5.2 5.4
32ºC D23ºC W Pressure( kg/cm
2
)
4.6 4.8 4.9 5.2 5.4 5.7
