10.3 MSH-09CR
SUMMER OUTDOOR TEMPERATURE DRY
Indoor Conditions
25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
Total capacity kW 2.44 2.32 2.16 1.98 1.82 1.70
Sensitive capacity kW
1.68 1.63 1.56 1.48 1.40 1.34
21ºC D
15ºC W
Input kW. 0.87 0.95 1.02 1.09 1.17 1.24
Total capacity kW 2.62 2.50 2.36 2.20 2.07 1.94
Sensitive capacity kW
1.78 1.73 1.67 1.61 1.56 1.54
24ºC D
17ºC W
Input kW. 0.87 0.95 1.03 1.11 1.20 1.28
Total capacity kW 2.80 2.75 2.60 2.40 2.18 1.99
Sensitive capacity kW
1.93 1.89 1.82 1.73 1.64 1.57
27ºC D
19ºC W
Input kW. 0.89 0.97 1.05 1.14 1.22 1.30
Total capacity kW 2.85 2.90 2.86 2.76 2.63 2.50
Sensitive capacity kW
1.83 1.85 1.84 1.81 1.78 1.79
32ºC D
23ºC W
Input kW. 0.88 0.98 1.07 1.17 1.27 1.37
10.4 MSH-09HR
SUMMER OUTDOOR TEMPERATURE DRY
Indoor Conditions
25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
Total capacity kW 2.44 2.32 2.16 1.98 1.82 1.70
Sensitive capacity kW
1.68 1.63 1.56 1.48 1.40 1.34
21ºC D
15ºC W
Input kW. 0.87 0.95 1.02 1.09 1.17 1.24
Total capacity kW 2.62 2.50 2.36 2.20 2.07 1.94
Sensitive capacity kW
1.78 1.73 1.67 1.61 1.56 1.54
24ºC D
17ºC W
Input kW. 0.87 0.95 1.03 1.11 1.20 1.28
Total capacity kW 2.80 2.75 2.60 2.40 2.18 1.99
Sensitive capacity kW
1.93 1.89 1.82 1.73 1.64 1.57
27ºC D
19ºC W
Input kW. 0.89 0.97 1.05 1.14 1.22 1.30
Total capacity kW 2.85 2.90 2.86 2.76 2.63 2.50
Sensitive capacity kW
1.83 1.85 1.84 1.81 1.78 1.79
32ºC D
23ºC W
Input kW. 0.88 0.98 1.07 1.17 1.27 1.37
WINTER OUTDOOR CONDITIONS
Indoor Conditions
12ºC D
11ºC W
7ºC D
6ºC W
4ºC D
3ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
-7ºC D
-8ºC W
Capacity kW 3.58 3.18 2.80 1.82 1.52 1.47
15ºC
Input kW. 1.18 1.05 0.94 0.81 0.75 0.80
Capacity kW 3.37 3.02 2.72 1.73 1.60 1.41
18ºC
Input kW. 1.20 1.05 0.96 0.86 0.83 0.84
Capacity kW 3.35 3.05 2.70 1.64 1.48 1.44
20ºC
Input kW. 1.24 1.08 0.98 0.86 0.82 0.82
Capacity kW 3.11 2.97 2.57 1.40 1.50 1.39
22ºC
Input kW. 1.14 1.07 0.98 0.86 0.82 0.79
