Service manual
31
9.8 MSH-16HR
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions
Pressure 25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
21ºC D15ºC W Pressure( kg/cm
2
)
4.2 4.3 4.4 4.5 4.7 4.9
24ºC D17ºC W Pressure( kg/cm
2
)
4.3 4.5 4.6 4.7 5.0 5.2
27ºC D19ºC W Pressure( kg/cm
2
)
4.4 4.6 4.7 4.9 5.2 5.4
32ºC D23ºC W Pressure( kg/cm
2
)
4.6 4.8 4.9 5.2 5.4 5.7
Heating mode OUTDOOR CONDITIONS
Indoor Conditions
Pressure
12ºC D
11ºC W
7ºC
D
6ºC W
0ºC D
-1ºC W
-4ºC D
-6ºC W
-7ºC D
-9ºC W
-15ºC D
-xºC W
15ºC Pressure( kg/cm
2
)
14.1 13.0 10.7 10.3 10.1 /
18ºC Pressure( kg/cm
2
)
15.3 14.1 12.3 11.4 11.1 /
20ºC Pressure( kg/cm
2
)
15.6 14.9 12.6 12.3 11.6 /
22ºC Pressure( kg/cm
2
)
16.6 15.6 13.1 12.6 11.9 /
9.9 MSH-18CR
Cooling mode Outdoor temperature (Dry bulb temp)
Indoor Conditions
Pressure 25ºC
30ºC
35ºC
40ºC
45ºC
50ºC
21ºC D15ºC W Pressure( kg/cm
2
)
4.3 4.3 4.4 4.5 4.7 4.9
24ºC D17ºC W Pressure( kg/cm
2
)
4.4 4.5 4.6 4.7 5.0 5.2
27ºC D19ºC W Pressure( kg/cm
2
)
4.5 4.6 4.7 4.9 5.2 5.5
32ºC D23ºC W Pressure( kg/cm
2
)
4.6 4.6 4.9 5.2 5.4 5.7
