4. Specification
Model MSH-07CR MSH-07HR MSH-09CR MSH-09HR
Power supply Ph-V-Hz
1,220-240V, 50Hz 1,220-240V, 50Hz 1,220-240V, 50Hz 1,220-240V~, 50Hz
Capacity Btu/h 7000 7000 9000 9000
Input W 800 800 1000 1000
Rated current A 3.6 3.6 4.5 4.5
Cooling
EER Btu/w.h
8.8 8.8 9.0 9.0
Capacity Btu/h / 7600 / 10000
Input W / 760 / 980
Rated current A / 3.4 / 4.4
Heating
COP W/W / 2.9 / 3.0
Max. input consumption W 1050 1050 1300 1300
Max. current A 5 5 7 7
Starting current A 18 18 25 25
Model 2P14C235ANA 2P14C235ANA PH165X1CY-4DG2 2P18SS225ANK
Type Rotary Rotary Rotary Rotary
Brand GD Matsushita GD Matsushita GD Toshiba GD Matsushita
Capacity Btu/h 7500 7500 9380 9920
Input W 725 725 900 970
Rated current(RLA) A 3.4 3.4 4.1 4.5
Locked rotor Amp(LRA) A 15 15 24 24
Thermal protector MRA98854 MRA98854
UP3QE0591-T61
(internal)
MRA98745
(external)
Capacitor uF 25 25 25 30
Compressor
Refrigerant oil ml ATOMOS M60 270 ATOMOS M60 270 SUNISO 400 SUNISO 350
Model RPG13H RPG13H RPG13H RPG13H
Brand WEILING WEILING WEILING WEILING
Input W 36.5 36.5 36.5 36.5
Capacitor uF 1.2uf/450V 1.2uf/450V 1.2uf/450V 1.2uf/450V
Indoor
fan motor
Speed(hi/mi/lo) r/min 1020/920/900 1020/920/900 1100/1020/950 1100/1020/950
Indoor air flow (Hi/Mi/Lo) m3/h 380/350/320 380/350/320 450/420/390 450/420/390
Indoor noise level (Hi/Mi/Lo) dB(A) 35/33/31 35/33/31 37/35/32 37/35/32
Model YDK24-6T YDK24-6T YDK24-6F YDK24-6F
Brand WEILING WEILING WEILING WEILING
Input W 70 70 70 70
Capacitor uF 3 3 2.5 2.5
Outdoor
fan motor
Speed r/min 850 850 850 850
Outdoor air flow m3/h 1500 1400 1500 1500
Outdoor noise level dB(A) 52 52 53 53
Refrigerant type R22 g 580 620 580 700
Liquid side/ Gas side mm φ6.35/φ9.53 φ6.35/φ9.53 φ6.35/φ9.53 φ6.35/φ9.53
Max. pipe length m 10 10 10 10
Refrigerant
piping
Max. in level m 5 5 5 5
Operation temp ℃ 17-30 17-30 17-30 17-30
Ambient temp ℃ 17-45 -7-45 17-45 -7-45
Application area m2 10-14 10-14 14-21 14-21
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
