Midea MSH-07CR User Manual

Service manual
7
2Model MSH-12CR MSH-12HR MSH-16CR MSH-16HR
Power supply Ph-V-Hz 1, 220-240V, 50Hz 1, 220-240V, 50Hz 1,220-240V, 50Hz 1,220-240V, 50Hz
Capacity Btu/h 12000 12000 16000 16000
Input W 1280 1320 1760 1760
Rated current A 6 6.1 8.6 8.6
Cooling
EER Btu/w.h 9.4 9.1 9.09 9.09
Capacity Btu/h / 14000 / 18500
Input W / 1370 / 1850
Rated current A / 6.3 / 8.9
Heating
COP W/W / 3.0 / 2.93
Max. input consumption W 1850 1850 2400 2400
Max. current A 9.6 9.6 11 11
Starting current A 29 30 36 36
Model PH240X2C-4FT 2K25S225BUA PH290X2C-4FT1 PH290X2C-4FT1
Type Rotary Rotary Rotary Rotary
Brand GD Toshiba GD Matsushita GD Toshiba GD Toshiba
Capacity Btu/h 14000 14700 17435 17435
Input W 1355 1468 1670 1670
Rated current(RLA) A 6.3 6.8 8.0 8.0
Locked rotor Amp(LRA) A 29 30 41.2 41.2
Thermal protector Internal Internal Internal Internal
Capacitor uF 35 40 35 35
Compressor
Refrigerant oil ml 480 490 520 520
Model RPG20D RPG20D RPG28D RPG28D
Brand WEILING WEILING WEILING WEILING
Input W 49.2 49.2 55 55
Capacitor uF 1.5uf/450V 1.5uf/450V 1.5UF/450V 1.5UF/450V
Indoor fan
motor
Speed(hi/mi/lo) r/min 1220/1000/800 1220/1000/800 1180/1080/800 1180/1080/800
Indoor air flow (Hi/Mi/Lo) m3/h 560/520/480 560/520/480 850/700/600 850/700/600
Indoor noise level (Hi/Mi/Lo) dB(A) 38/32/28 38/32/28 44/41/38 44/41/38
Model YDK24-6 YDK25-6 YDK36-6 YDK36-6
Brand WEILING WEILING WEILING WEILING
Input W 72 96 96 96
Capacitor uF 2.5uf/450V 2.5uf/450V 2.5uf/450V 2.5uf/450V
Outdoor fan
motor
Speed r/min 850 900 900 900
Outdoor air flow m3/h 1900 1900 1800 1800
Outdoor noise level dB(A) 53 53 54 54
Refrigerant type R22 g 830 1080 1050 1400
Liquid side/ Gas side mm φ6.35/φ12.7 φ6.35/φ12.7 φ6.35/φ12.7 φ6.35/φ12.7
Max. pipe length m 10 10 10 10
Refrigerant
piping
Max. in level m 5 5 5 5
Operation temp ℃ 17-30 17-30 17-30 17-30
Ambient temp ℃ 17-45 -7-45 17-45 -7-45
Application area m2 18-26 18-26 28-40 28-40
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
