Service manual
8
Model MSH-18CR
Power supply Ph-V-Hz 1, 220-240V~, 50Hz
Capacity Btu/h 18000
Input W 1980
Rated current A 9.0
Cooling
EER Btu/w.h 9.09
Capacity Btu/h /
Input W /
Rated current A /
Heating
COP W/W /
Max. input consumption W 2100
Max. current A 12.0
Starting current A 42
Model SHW33TC4-U
Type Rotary
Brand 上海日立
Capacity Btu/h 20438
Input W 1990
Rated current(RLA) A 9.3
Locked rotor Amp(LRA) A 41.2
Thermal protector Internal
Capacitor uF 50
Compressor
Refrigerant oil ml 600
Model RPG28D
Brand WEILING
Input W 55
Capacitor uF 1.5UF/450V
Indoor fan motor
Speed(hi/mi/lo) r/min 1180/1080/800
Indoor air flow (Hi/Mi/Lo) m3/h 850/700/600
Indoor noise level (Hi/Mi/Lo) dB(A) 44/41/38
Model YDK53-6
Brand WEILING
Input W 100
Capacitor uF 2.5uf
Outdoor fan motor
Speed r/min 640
Outdoor air flow m3/h 2200
Outdoor noise level dB(A) 54
Refrigerant type (R22) g 1220
Liquid side/ Gas side mm φ6.35/φ12.7
Max.pipe length m 15
Refrigerant piping
Max. in level m 8
Operation temp ℃ 17-30
Ambient temp ℃ 17-45
Application area m2 34－49
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
