Midea R410A T3 Top-discharge Split Type Series 50Hz MCAC-UTSM-201501
11
Model
MTA-120HRN1
MTA-120CRN1
Type
Medium static pressure duct
Power supply
\
220-240V~, 1Ph, 50Hz
Cooling
Capacity (T1/T3)
Btu/h
119,400/102,400
119,400/102,400
W
35,000/30,000
35,000/30,000
Input (T1/T3)
W
12,000/13,250
12,000/13,250
EER (T1)
W/W
2.92
2.92
Heating
Capacity
Btu/h
130,000
\
W
38,000
\
Input
W
12,600
\
COP
W/W
3.02
\
Rated input (Whole units)
W
17,300
17,300
Rated current (Whole units)
A
28.6
28.5
Indoor air flow
m
3
/h
6,375
6,375
Indoor standard ESP (External static pressure)
Pa
150
150
Indoor noise level
dB(A)
63
63
Refrigerant type
\
R410A
R410A
Refrigerant control
\
Capillary
Fan
Type
\
Centrifugal fan
Centrifugal fan
Motor model (×Quantity)
\
YDK250-4X(×3)
YDK250-4X(×3)
Input (Hi/med/lo)
W
570/475/430
570/475/430
Capacitor
\
15μF/450V
15μF/450V
Speed (Hi/med/lo)
r/min
930/850/770
930/850/770
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7
Ф7
No. of rows
\
4
4
Fin spacing
mm
1.5
1.5
Tube pitch(a)×row pitch(b)
mm
21×13.37
21×13.37
Length× height
mm
1,602×588
1,602×588
Number of circuits
\
42
42
Controller
\
R51/E
R51/CE
Refrigerant pipe (Liquid/ Gas)
mm
Ф12.7/Ф28.6
Ф12.7/Ф28.6
Drain pipe size
mm
Ф41
Ф41
Dimension (W×H×D)
mm
1,988×669×906
1,988×669×906
Packing (W×H×D)
mm
2,095×800×964
2,095×800×964
Net/Gross weight
kg
188/220
188/220
Notes:
1. Nominal cooling capacities are based on the following conditions:
T1: Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°C WB; T3: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 46°CDB; Equivalent refrigerant piping: 7.5m (horizontal).
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB, 15°C WB; Outdoor temp: 7°CDB, 6°CWB; Equivalent refrigerant piping: 7.5m (horizontal).
