Midea MTA-76C(H)RN1 User Manual

MCAC-UTSM-201501 Midea R410A T3 Top-discharge Split Type Series 50Hz
12
Model
MTA-150CRN1
Type
Medium static pressure duct
Power supply
\
220-240V~, 1Ph, 50Hz
Cooling
Capacity (T1/T3)
Btu/h
150,100/130,300
W
44,000/38,200
Input (T1/T3)
W
15,100/18,000
EER (T1)
W/W
2.91
Heating
Capacity
Btu/h
\
W
\
Input
W
\
COP
W/W
\
Rated input (Whole units)
W
21,200
Rated current (Whole units)
A
35
Indoor air flow
m
3
/h
7,650
Indoor standard ESP (External static pressure)
Pa
150
Indoor noise level
dB(A)
79
Refrigerant type
\
R410A
Refrigerant control
\
Capillary
Fan
Type
\
Centrifugal fan
Motor model (×Quantity)
\
YDK300-4X(×3)
Input (Hi/med/lo)
W
720/605/510
Capacitor
\
15μF/450V
Speed (Hi/med/lo)
r/min
1,040/930/825
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7
No. of rows
\
4
Fin spacing
mm
1.5
Tube pitch(a)×row pitch(b)
mm
21×13.37
Length× height
mm
1,602×588
Number of circuits
\
28
Controller
\
R51/CE
Refrigerant pipe (Liquid/ Gas)
mm
(Ф9.52/Ф22)×2
Drain pipe size
mm
Ф41
Dimension (W×H×D)
mm
1,988×669×906
Packing (W×H×D)
mm
2,095×800×964
Net/Gross weight
kg
188/200
Notes:
1. Nominal cooling capacities are based on the following conditions:
T1: Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°C WB; T3: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 46°CDB; Equivalent refrigerant piping: 7.5m (horizontal).
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB, 15°C WB; Outdoor temp: 7°CDB, 6°CWB; Equivalent refrigerant piping: 7.5m (horizontal).
