Midea MTA-76C(H)RN1

Midea R410A T3 Top-discharge Split Type Series 50Hz MCAC-UTSM-201501
87
 Upon completion of wire connection, double check it and then connect the power supply.
 An all-pole disconnection device which has at least 3mm separation distance in all pole and a
residual current device (RCD) with the rating of above 10mA shall be incorporated in the fixed
wiring according to the national rule.
 The appliance shall be installed in accordance with national wiring regulations.
7.2 Specifications of power supply
Medium static pressure duct:
Type
Duct type indoor unit
Outdoor unit
Model
MTA-76C(H)RN1
MTA-150CRN1
MOV-76C(H)N1-C
Power
220-240V~, 1Ph, 50Hz
380~415V~, 3Ph, 50Hz
Switch capacity of the
main power supply / Fuse
20A/8A
20A/12A
60A/40A
Indoor unit power cable
3×2.5mm
2
(Includes grounded wire)
/
Outdoor unit power cable
\
Single unit: 5×6mm
2
Power-main unit: 5×10mm
2
Main-auxil unit: 5×6mm
2
Connective wire of indoor
and outdoor unit
4×1.0mm
2
(Cooling & heating)
2×1.0mm
2
(Cooling only)
Wired controller
connective wire
5×0.5mm
2
(Shield wire)
\
Type
Indoor unit
Outdoor unit
Model
MTA-96C(H)RN1
MOV-96C(H)N1-C
Power
220-240V~, 1Ph, 50Hz
380~415V~, 3Ph, 50Hz
Switch capacity of the main
power supply / Fuse
20A/8A
60A/40A
Indoor unit power cable
3×2.5mm
2
(Includes grounded wire)
/
Outdoor unit power cable
\
5×6.0mm
2
Connective wire of indoor
and outdoor unit
4×1.0mm
2
(Cooling & heating)
2×1.0mm
2
(Cooling only)
Wired controller connective
wire
5×0.5mm
2
(Shield wire)
\
