MCAC-UTSM-201501 Midea R410A T3 Top-discharge Split Type Series 50Hz
88
Medium static pressure duct:
Type
Indoor unit
Outdoor unit
Model
MTA-120C(H)RN1
MOV-120C(H)N1-C
Power
220-240V~, 1Ph, 50Hz
380~400V~, 3Ph, 50Hz
Switch capacity of the main
power supply / Fuse
40A/20A
60A/40A
Indoor unit power cable
3×2.5mm
2
(Includes grounded wire)
/
Outdoor unit power cable
\
5×6.0mm
2
Connective wire of indoor
and outdoor unit
4×1.0mm
2
(Cooling & heating)
2×1.0mm
2
(Cooling only)
Wired controller connective
wire
5×0.5mm
2
(Shield wire)
\
High static pressure duct:
Type
Indoor unit
Outdoor unit
Model
MHB-76C(H)RN1
MOV-76C(H)N1-C
Power
220-240V~, 1Ph, 50Hz
380~415V~, 3Ph, 50Hz
Switch capacity of the main
power supply / Fuse
20A/8A
60A/40A
Indoor unit power cable
3×2.5mm
2
(Includes grounded wire)
/
Outdoor unit power cable
\
5×6.0mm
2
Connective wire of indoor
and outdoor unit
4×1.0mm
2
(Cooling & heating)
2×1.0mm
2
(Cooling only)
Wired controller connective
wire
5×0.5mm
2
(Shield wire)
\
High static pressure duct:
Type
Indoor unit
Outdoor unit
Model
MHB-96C(H)RN1
MOV-96C(H)N1-C
Power
220-240V~, 1Ph, 50Hz
380~415V~, 3Ph, 50Hz
Switch capacity of the main
power supply / Fuse
20A/12A
60A/40A
Indoor unit power cable
3×2.5mm
2
(Includes grounded wire)
/
Outdoor unit power cable
\
5×6.0mm
2
Connective wire of indoor
and outdoor unit
4×1.0mm
2
(Cooling & heating)
2×1.0mm
2
(Cooling only)
Wired controller connective
wire
5×0.5mm
2
(Shield wire)
\
