Midea MTB1T-96CWN1 User Manual

Midea R410A T3 50Hz Top-discharge Series MCAC-UTSM-201707
11
Model
MHB1T-96HWN1
MHB1T-96CWN1
Power supply
\
220-240V~, 1Ph, 50Hz
220-240V~, 1Ph, 50Hz
T1 Cooling
Capacity
Btu/h
96,000
96,000
W
28,100
28,100
Input
W
9,600
9,600
EER
W/W
2.93
2.93
T3 Cooling
Capacity
Btu/h
87,860
87,860
W
25,750
25,750
Input
W
15,000
15,000
EER
W/W
1.72
1.72
Heating
Capacity
Btu/h
106,000
\
W
31,100
\
Input
W
10,300
\
COP
W/W
3.02
\
Rated input
W
1,400
1,400
Rated current
A
5.8
5.8
Fan motor
Fan type
\
Centrifugal
Centrifugal
Model (× Quantity)
\
YDK550-4X
YDK550-4X
Motor quantity
\
2
2
Brand
\
Matchwell/Yongan
Matchwell/Yongan
Input (Hi/Med/Lo)
W
910/780/680
910/780/680
Capacitor
\
20μF/450V
20μF/450V
Speed (Hi/Med/Lo)
r/min
1,320/1,230/1,120
1,320/1,230/1,120
Indoor coil
Number of rows
\
4
4
Tube pitch(a)×row pitch(b)
mm
25.4×22
25.4×22
Fin spacing
mm
1.5
1.5
Fin type
\
Hydrophilic aluminum fin
Hydrophilic aluminum fin
Tube size
mm
Ф9.52
Ф9.52
Tube type
\
Inner grooved copper pipe
Inner grooved copper pipe
Coil(W×H)
mm
1,202×406.4
1,202×406.4
Number of circuits
\
16
16
Indoor air flow
m
3
/h
5100
5100
External static pressure
Pa
196
196
Indoor noise pressure level
dB(A)
56
56
Refrigerant
Type
\
R410A
R410A
Control
\
Capillary
Capillary
Design pressure
MPa
4.4/2.6
4.4/2.6
Refrigerant pipe (Liquid side/ Gas side)
mm
Ф12.7/Ф25.4#
Ф12.7/Ф25.4#
Connection wire
Power wire
\
3×2.5mm
2
3×2.5mm
2
Signal wire
\
4×1.0mm
2
2×1.0mm
2
Continued:

Midea MTB1T-96CWN1 Specifications

General

Brand	Midea
Model	MTB1T-96CWN1
Category	Air Conditioner
Language	English
