1. Specifications
Model
MOVTA-96HN1-R
MOVTA-96CN1-R
Power supply
\
380-415V~, 3Ph, 50Hz
380-415V~, 3Ph, 50Hz
Ambient temperature in cooling
°C
17 - 46
17～46
Ambient temperature in heating
°C
-7 - 24
\
Rated input
W
14,400
14,400
Rated current
A
23.7
23.7
Compressor
Model
\
HCJ121T4LC6
HCJ121T4LC6
Type (×Quantity)
\
Scroll (×1)
Scroll (×1)
Brand
\
Danfoss
Danfoss
Capacity
W
29,717
29,717
Input
W
9,224
9,224
Rated current (RLA)
A
17.9
17.9
Locked rotor Amp (LRA)
A
125
125
Thermal protector
\
Internal
Internal
Refrigerant oil
ml
2,460 (PVE)
2,460 (PVE)
Fan motor
Type
\
Axial fan
Axial fan
Motor Model
\
YDK400-4C
YDK400-4C
Quantity
2
2
Motor Brand
\
Welling/Yongan
Welling/Yongan
Capacitor
\
25μF/450V
25μF/450V
Motor Input(4/3 fan blades)
W
(587/388)/(612/388)
(587/388)/(612/388)
Speed (4/3 fan blades)
r/min
(1,230/870)/(1,180/790)
(1,230/870)/(1,180/790)
Coil
No. of rows
\
3
2
Tube pitch(a)×row pitch(b)
mm
21×13.37
22×19.05
Fin spacing
mm
1.3
1.4
Fin type
\
Hydrophilic aluminum fin
Tube outside diameter
mm
Ф7
Ф8
Tube type
Inner grooved copper pipe
Coil (W×H)
mm
2,179×882
2,177×880
Number of circuits
\
20
18
Outdoor noise pressure level
dB(A)
68
68
Outdoor airflow
m
3
/h
12,000
12,000
Refrigerant
Type
\
R410A
R410A
Charge
g
6,000
6,000
Design pressure
MPa
4.4/2.6
4.4/2.6
Refrigerant pipe (Liquid side/ Gas side)
mm
Ф12.7/Ф25.4#
Ф12.7/Ф25.4#
Connection
wiring
Power wire
\
\
\
Signal wire
\
2×1.0
2×1.0
Outdoor unit
Dimension (W×H×D)
mm
1,312×919×658
1,312×919×658
Packing (W×H×D)
mm
1,320×1,060×730
1,320×1,060×730
Net/ Gross weight
kg
177/192
168/183
