System check (SW2)
SW2: (CHECK)――Used to query outdoor unit data. Check point sequence and corresponding actuality is as
follows:
Content (present frequency)
Master unit: 0; slave unit: 1, 2, 3.
Available for master unit
Setting quantity of indoor unit
Available for master unit
Total capacity of outdoor units
Available for master unit
Total capacity requirement of indoor units
Total correct capacity requirement of master unit
Actual running capacity of this outdoor unit
Temperature of evaporator pipe (T2B/T2)
Actual value=display value
Temperature of condenser pipe (T3)
Actual value=display value
Temperature of outdoor ambient (T4)
Actual value=display value
Discharge temperature of inverter compressor A
Actual value=display value
Discharge temperature of inverter compressor B
Actual value=display value
Main inverter module temperature
Actual value=display value
Saturation temperature corresponding to the discharge pressure
Actual value=display value+30
Current of inverter compressor A
Actual value=display value
Current of inverter compressor B
Actual value=display value
Pulse value=display value×8
Pulse value=display value×8
Actual value=display value×0.1MPa
Quantity of indoor units which are communicated with master unit
Actual value=display value
Quantity of working indoor units
Actual value=display value
Actual value=display value×10
Actual value=display value×10
The last error or protection code
Display 000 if it has no error or protection
Actual value=display value
Note:
1. Outdoor unit capacity setting: 0—8HP; 1—10HP; 2—12HP; 3—14HP; 4—16HP; 5—18HP.
2. Running mode: 0—OFF; 2—cooling mode; 3—heating mode; 4—forced cooling mode.
3. Fan speed: 0—stop; 1~15—fan speed sequentially increased.
4. Priority mode: 0—heating priority mode; 1—cooling priority mode; 2—VIP (address no. 63) priority mode or voting priority
mode; 3—heating only priority mode; 4—cooling only priority mode.
5. Silent mode: 0—night silent mode; 1—silent mode; 2—super silent mode; 3—no silent mode.
6. Static pressure mode: 0—none static pressure; 1—low static pressure; 2—medium static pressure; 3—high static pressure.
Normal display: When the outdoor unit is on standby, the first two numbers on LED digital tube will display the address of the
outdoor unit, and the last two numbers display the indoor unit’s quantity which can communicate with outdoor unit. When the
outdoor unit is operating, it will display the rotation frequency of the compressor.
System check steps:
1. Ensure the system operates steadily for more than 1 hour;
2. Press the check button (SW2) on main PCB of outdoor master unit;
3. Check the parameters one by one and fill out the commissioning tables.
