Midea V5 X VRF Series - Page 23

MCAC-VTSM-2015-10 R410A All DC Inverter V5 X Series 50Hz
Specifications & Performances 21
Refrigerant
Type
R410A
Factory charging
kg
9
9
11
Pipe
connections
Liquid pipe
mm
Φ12.7
Φ12.7
Φ15.9
Gas pipe
mm
Φ22.2
Φ22.2
Φ28.6
Oil balance pipe
mm
Φ8
Design pressure(High/low)
MPa
4.4/2.6
Air flow rate
m
3
/h
12000
Sound pressure level
dB(A)
58
59
60
Net dimension (W×H×D)
mm
990×1635×790
Packing size (W×H×D)
mm
1090×1805×860
Net weight
kg
219
219
237
Gross weight
kg
234
234
252
Operating temperature range
°C
Cooling: -5~48; Heating: -20~24
Notes:
Capacities are based on the following conditions:
Cooling: Indoor temperature 27
o
C DB/19
o
C WB; Outdoor temperature 35
o
C DB/24
o
C WB;
Heating: Indoor temperature 20
o
C DB/15
o
C WB; Outdoor temperature 7
o
C DB/6
o
C WB.
Piping length: Interconnecting piping length is 7.5m, level difference is zero.
Sound values are measured in a semi-anechoic room, at a position of 1m in front of the unit and 1.3m above the floor.
