Midea V5 X VRF Series - Page 39

MCAC-VTSM-2015-10 R410A All DC Inverter V5 X Series 50Hz
Specifications & Performances 37
Cooling capacity tables
8HP CR: Combination Ratio; TC: Total Capacity (kW); PI: Power Input (kW) (Compressor + Outdoor fan motor)
CR
Outdoor
temp.
(°C DB)
Indoor temperature(°C DB/WD)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
10%
-5
1.68
0.19
2.02
0.22
3.18
0.25
2.24
0.22
2.92
0.28
3.12
0.32
3.55
0.34
-2
1.68
0.19
2.02
0.22
3.18
0.25
2.24
0.22
2.92
0.29
3.12
0.32
3.55
0.36
0
1.68
0.19
2.02
0.22
3.18
0.26
2.24
0.22
2.92
0.29
3.12
0.33
3.55
0.36
2
1.68
0.19
2.02
0.23
3.18
0.26
2.24
0.22
2.92
0.30
3.12
0.33
3.55
0.37
4
1.68
0.20
2.02
0.23
3.18
0.26
2.24
0.22
2.92
0.30
3.12
0.34
3.55
0.38
6
1.68
0.20
2.02
0.23
3.18
0.27
2.24
0.23
2.92
0.30
3.12
0.34
3.55
0.38
8
1.68
0.20
2.02
0.23
3.18
0.27
2.24
0.23
2.92
0.31
3.12
0.35
3.55
0.39
10
1.68
0.20
2.02
0.24
3.18
0.28
2.24
0.23
2.92
0.32
3.12
0.37
3.55
0.42
12
1.68
0.21
2.02
0.25
3.18
0.29
2.24
0.23
2.92
0.32
3.12
0.39
3.55
0.44
14
1.68
0.22
2.02
0.26
3.18
0.31
2.24
0.23
2.92
0.33
3.12
0.41
3.55
0.47
16
1.68
0.23
2.02
0.24
3.18
0.33
2.24
0.23
2.92
0.35
3.12
0.44
3.55
0.49
18
1.68
0.25
2.02
0.28
3.18
0.35
2.24
0.23
2.92
0.36
3.12
0.46
3.55
0.51
20
1.68
0.26
2.02
0.31
3.18
0.37
2.24
0.24
2.92
0.38
3.12
0.48
3.55
0.52
21
1.68
0.27
2.02
0.33
3.18
0.39
2.24
0.26
2.92
0.40
3.12
0.50
3.55
0.54
23
1.68
0.29
2.02
0.35
3.18
0.41
2.24
0.27
2.92
0.45
3.12
0.52
3.55
0.56
25
1.68
0.30
2.02
0.36
3.18
0.43
2.24
0.29
2.92
0.48
3.12
0.55
3.55
0.58
27
1.68
0.32
2.02
0.39
3.18
0.44
2.24
0.32
2.92
0.51
3.12
0.56
3.55
0.60
29
1.68
0.33
2.02
0.40
3.18
0.47
2.24
0.34
2.92
0.52
3.12
0.58
3.55
0.61
31
1.68
0.34
2.02
0.41
3.18
0.48
2.24
0.35
2.92
0.53
3.12
0.60
3.55
0.64
33
1.68
0.36
2.02
0.45
3.18
0.50
2.24
0.37
2.92
0.54
3.12
0.61
3.55
0.65
35
1.68
0.40
2.02
0.49
3.18
0.52
2.24
0.40
2.92
0.56
3.12
0.63
3.55
0.68
37
1.68
0.45
2.02
0.50
3.18
0.54
2.24
0.40
2.92
0.57
3.12
0.65
3.55
0.69
39
1.68
0.47
2.02
0.52
3.18
0.56
2.24
0.41
2.92
0.60
3.12
0.67
3.55
0.71
41
1.68
0.48
2.02
0.54
3.18
0.57
2.24
0.42
2.92
0.61
3.12
0.69
3.55
0.72
43
1.68
0.50
2.02
0.55
3.18
0.59
2.24
0.42
2.92
0.63
3.12
0.70
3.55
0.76
45
1.68
0.52
2.02
0.56
3.18
0.60
2.24
0.43
2.92
0.64
3.12
0.72
3.55
0.60
48
1.68
0.39
2.02
0.41
3.18
0.45
2.24
0.44
2.92
0.45
3.12
0.49
3.55
0.41
Cooling capacity tables
10HP CR: Combination Ratio; TC: Total Capacity (kW); PI: Power Input (kW) (Compressor + Outdoor fan motor)
CR
Outdoor
temp.
(°C DB)
Indoor temperature(°C DB/WD)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
130%
-5
24.89
3.02
30.26
3.38
34.13
3.65
35.12
3.96
37.55
4.23
38.59
4.59
38.88
4.62
-2
24.89
3.02
30.26
3.45
34.13
3.65
35.12
3.98
37.55
4.23
38.59
4.65
38.88
4.67
0
24.89
3.07
30.26
3.52
34.13
3.79
35.12
4.21
37.55
4.47
38.59
4.71
38.88
4.73
2
24.89
3.12
30.26
3.53
34.13
3.93
35.12
4.45
37.55
4.52
38.59
4.74
38.88
4.80
4
24.89
3.19
30.26
3.60
34.13
4.08
35.12
4.47
37.55
4.58
38.59
4.74
38.88
4.89
6
24.89
3.26
30.26
3.68
34.13
4.24
35.12
4.51
36.91
4.72
37.47
4.74
38.46
4.93
8
24.89
3.33
30.26
3.77
34.13
4.47
35.12
4.74
36.54
4.88
37.06
4.76
37.97
4.98
10
24.89
3.40
30.26
3.86
34.13
4.64
35.12
4.90
36.19
4.91
36.63
4.91
37.53
5.12
12
24.89
3.46
30.26
3.94
34.13
4.74
35.04
4.96
35.33
5.04
36.13
5.00
37.03
5.15
14
24.89
3.53
30.26
4.02
33.93
4.76
34.75
4.99
34.83
5.09
35.73
5.09
36.63
5.27
16
24.89
3.59
30.26
4.11
33.53
4.90
34.14
5.09
34.33
5.19
35.23
5.20
36.13
5.35
18
24.89
3.66
30.26
4.20
33.03
4.97
33.59
5.15
33.93
5.33
34.83
5.38
35.73
5.43
20
24.89
3.74
30.26
4.48
32.53
5.23
33.03
5.41
33.43
5.59
34.33
5.64
35.23
5.70
21
24.89
3.84
30.26
4.65
32.33
5.36
32.83
5.54
33.23
5.72
34.13
5.78
35.03
5.83
23
24.89
4.12
30.26
5.01
31.93
5.62
32.33
5.80
32.73
5.98
33.63
6.04
34.53
6.10
25
24.89
4.40
30.26
5.39
31.43
5.88
31.83
6.06
32.33
6.25
33.23
6.31
34.13
6.37
27
24.89
4.70
30.26
5.79
31.03
6.14
31.43
6.45
31.83
6.51
32.73
6.58
33.63
6.65
29
24.89
5.02
30.26
6.21
30.52
6.40
30.92
6.80
31.43
6.78
32.33
6.85
33.23
6.92
31
24.89
5.35
29.22
6.58
30.02
6.66
30.52
7.13
30.92
7.03
31.83
7.11
32.73
7.19
33
24.89
5.70
28.72
6.84
29.62
6.92
30.02
7.52
30.52
7.30
31.43
7.38
32.22
7.46
35
24.89
6.08
28.22
7.10
29.12
7.19
29.62
7.53
30.02
7.57
30.92
7.66
31.83
7.74
37
24.89
6.47
27.82
7.37
28.72
7.46
29.12
7.65
29.62
7.85
30.42
7.94
31.32
8.03
39
24.89
6.89
27.32
7.45
28.22
7.72
28.72
7.92
29.12
8.12
30.02
8.21
30.92
8.31
41
24.89
7.25
27.04
7.53
27.93
7.79
28.43
7.99
28.83
8.19
29.73
8.23
29.74
8.38
43
24.89
7.43
26.84
7.56
27.78
7.82
28.28
8.03
28.53
8.21
29.19
8.24
29.39
8.40
45
24.89
7.80
26.67
7.64
27.48
7.89
27.98
8.08
28.12
8.24
28.39
8.27
28.81
8.56
48
24.62
8.08
27.63
7.89
29.96
7.97
30.52
8.16
30.76
8.34
30.63
8.41
31.19
8.44
