Midea V5 X VRF Series User Manual

R410A All DC Inverter V5 X Series 50Hz MCAC-VTSM-2015-10
52 Specifications & Performances
Cooling capacity tables
16HP CR: Combination Ratio; TC: Total Capacity (kW); PI: Power Input (kW) (Compressor + Outdoor fan motor)
CR
Outdoor
temp.
(°C DB)
Indoor temperature(°C DB/WD)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
100%
-5
31.57
4.58
37.06
4.99
44.37
5.51
45.00
6.46
47.89
6.31
53.84
6.99
56.89
7.71
-2
31.57
4.65
37.06
5.06
44.37
5.62
45.00
6.51
47.89
6.40
53.84
7.08
56.89
7.76
0
31.57
4.70
37.06
5.12
44.37
5.71
45.00
6.61
47.89
6.46
53.84
7.21
56.89
7.85
2
31.57
4.77
37.06
5.18
44.37
5.84
45.00
6.67
47.89
6.54
53.84
7.32
56.89
7.97
4
31.57
4.81
37.06
5.27
44.37
5.91
45.00
6.77
47.89
6.63
53.84
7.40
56.89
8.06
6
31.57
4.92
37.06
5.35
44.37
6.02
45.00
6.91
47.89
6.73
53.84
7.51
56.89
8.19
8
31.57
4.99
37.06
5.46
44.37
6.13
45.00
7.04
47.89
6.85
53.84
7.64
56.89
8.33
10
31.57
5.09
37.06
5.56
44.37
6.23
45.00
7.15
47.89
6.98
53.84
7.78
56.89
8.46
12
31.57
5.20
37.06
5.68
44.37
6.46
45.00
7.29
47.89
7.12
53.84
7.93
56.09
8.52
14
31.57
5.30
37.06
5.80
44.37
6.76
45.00
7.75
47.89
7.26
53.84
8.10
55.44
8.63
16
31.57
5.40
37.06
5.94
44.37
6.93
45.00
7.95
47.89
7.41
53.52
8.21
54.64
8.73
18
31.57
5.51
37.06
6.06
44.37
7.19
45.00
8.26
47.89
7.57
52.88
8.50
54.00
8.96
20
31.57
5.63
37.06
6.27
44.37
7.79
45.00
8.83
47.89
8.14
52.07
8.93
53.19
9.40
21
31.57
5.68
37.06
6.53
44.37
8.35
45.00
9.36
47.89
8.43
51.75
9.16
52.88
9.63
23
31.57
6.07
37.06
7.05
44.37
8.98
45.00
10.01
47.89
9.07
51.11
9.61
52.07
10.08
25
31.57
6.51
37.06
7.60
44.37
9.69
45.00
10.51
47.89
9.74
50.31
10.06
51.43
10.53
27
31.57
6.95
37.06
8.17
44.37
10.26
45.00
11.14
47.89
10.45
49.50
10.50
50.63
10.99
29
31.57
7.44
37.06
8.77
44.37
11.03
45.00
11.47
47.73
11.12
48.86
10.97
49.98
11.44
31
31.57
7.96
37.06
9.41
44.37
11.80
45.00
11.68
47.09
11.57
48.06
11.42
49.18
11.91
33
31.57
8.49
37.06
10.08
44.37
12.36
45.00
12.01
46.29
12.02
47.41
11.87
48.54
12.37
35
31.57
9.04
37.06
10.81
44.37
12.61
45.00
12.80
45.48
12.47
46.61
12.33
47.73
12.82
37
31.57
9.65
37.06
11.57
44.37
12.70
44.19
12.90
45.00
12.93
45.96
12.80
46.93
13.29
39
31.57
10.27
37.06
12.36
44.37
12.93
43.58
12.93
45.00
13.38
45.16
13.25
46.29
13.77
41
31.57
10.65
37.06
12.84
44.37
13.12
43.29
13.12
45.00
13.59
44.38
13.57
45.61
14.06
43
31.57
11.03
37.06
13.09
44.37
13.21
43.14
13.21
45.00
13.73
44.64
13.67
44.81
14.22
45
31.57
11.55
37.06
13.33
44.37
13.34
42.86
13.34
45.00
13.99
44.26
13.89
43.91
14.41
48
30.91
11.88
36.79
13.26
42.84
13.42
42.43
13.42
45.00
14.14
42.29
13.94
43.70
14.45
90%
-5
27.32
3.45
32.63
3.93
37.93
4.57
40.50
5.12
43.07
5.67
48.37
6.52
53.68
7.47
-2
27.32
3.49
32.63
3.97
37.93
4.63
40.50
5.20
43.07
5.74
48.37
6.59
53.68
7.54
0
27.32
3.54
32.63
4.03
37.93
4.71
40.50
5.26
43.07
5.82
48.37
6.66
53.68
7.60
2
27.32
3.59
32.63
4.08
37.93
4.76
40.50
5.34
43.07
5.91
48.37
6.80
53.68
7.71
4
27.32
3.65
32.63
4.14
37.93
4.85
40.50
5.42
43.07
5.98
48.37
6.91
53.68
7.83
6
27.32
3.70
32.63
4.23
37.93
4.94
40.50
5.53
43.07
6.09
48.37
7.01
53.68
7.96
8
27.32
3.77
32.63
4.31
37.93
5.05
40.50
5.60
43.07
6.19
48.37
7.14
53.68
8.03
10
27.32
3.84
32.63
4.41
37.93
5.14
40.50
5.69
43.07
6.33
48.37
7.24
53.68
8.16
12
27.32
3.90
32.63
4.50
37.93
5.25
40.50
5.79
43.07
6.45
48.37
7.37
53.68
8.31
14
27.32
3.97
32.63
4.58
37.93
5.35
40.50
5.90
43.07
6.57
48.37
7.51
53.68
8.46
16
27.32
4.04
32.63
4.66
37.93
5.46
40.50
6.02
43.07
6.70
48.37
7.66
53.68
8.61
18
27.32
4.11
32.63
4.77
37.93
5.56
40.50
6.14
43.07
6.84
48.37
7.81
53.68
8.88
20
27.32
4.19
32.63
4.88
37.93
5.68
40.50
6.27
43.07
7.09
48.37
8.40
53.68
9.30
21
27.32
4.22
32.63
4.92
37.93
5.78
40.50
6.75
43.07
7.34
48.37
8.70
53.68
9.52
23
27.32
4.31
32.63
5.12
37.93
6.22
40.50
7.33
43.07
7.88
48.37
9.33
53.68
9.95
25
27.32
4.54
32.63
5.49
37.93
6.67
40.50
7.67
43.07
8.41
48.37
9.99
53.68
10.39
27
27.32
4.83
32.63
5.85
37.93
7.14
40.50
8.27
43.07
9.00
48.37
10.69
53.68
10.83
29
27.32
5.14
32.63
6.26
37.93
7.64
40.50
8.73
43.07
9.62
48.37
11.18
53.68
11.26
31
27.32
5.46
32.63
6.68
37.93
8.16
40.50
9.45
43.07
10.26
48.37
11.61
53.68
11.71
33
27.32
5.80
32.63
7.11
37.93
8.73
40.50
10.17
43.07
10.94
48.37
12.07
53.68
12.15
35
27.32
6.17
32.63
7.58
37.93
9.32
40.50
10.63
43.07
11.66
48.37
12.50
53.68
12.60
37
27.32
6.54
32.63
8.07
37.93
9.94
40.50
11.10
43.07
12.43
48.37
12.94
53.68
13.04
39
27.32
6.94
32.63
8.60
37.93
10.59
40.50
11.28
43.07
13.24
48.37
13.39
53.68
13.49
41
27.32
7.18
32.63
9.00
37.93
10.99
40.50
11.49
43.07
13.32
48.37
13.73
53.68
13.81
43
27.32
7.52
32.63
9.40
37.93
11.39
40.50
11.71
43.07
13.60
48.37
13.91
53.68
14.02
45
27.32
8.00
32.63
9.88
37.93
11.87
40.50
11.92
43.07
13.98
48.37
14.06
53.68
14.21
48
27.32
7.22
32.63
8.81
37.93
10.49
40.50
12.02
43.07
12.05
48.37
12.18
53.68
12.31
80%
-5
24.27
2.88
28.93
3.41
33.59
3.87
36.00
3.40
38.41
4.62
43.07
5.34
47.73
6.09
-2
24.27
2.92
28.93
3.45
33.59
3.90
36.00
3.41
38.41
4.66
43.07
5.39
47.73
6.15
0
24.27
2.98
28.93
3.49
33.59
3.95
36.00
3.48
38.41
4.75
43.07
5.47
47.73
6.24
2
24.27
3.03
28.93
3.54
33.59
4.01
36.00
3.63
38.41
4.83
43.07
5.58
47.73
6.36
4
24.27
3.09
28.93
3.60
33.59
4.09
36.00
3.65
38.41
4.92
43.07
5.68
47.73
6.44
6
24.27
3.14
28.93
3.69
33.59
4.15
36.00
3.75
38.41
5.01
43.07
5.76
47.73
6.55
8
24.27
3.20
28.93
3.77
33.59
4.26
36.00
3.89
38.41
5.12
43.07
5.85
47.73
6.68
10
24.27
3.22
28.93
3.86
33.59
4.37
36.00
3.93
38.41
5.24
43.07
5.98
47.73
6.75
12
24.27
3.27
28.93
3.92
33.59
4.45
36.00
4.03
38.41
5.35
43.07
6.10
47.73
6.87
14
24.27
3.33
28.93
4.00
33.59
4.53
36.00
4.11
38.41
5.44
43.07
6.21
47.73
7.00
16
24.27
3.38
28.93
4.06
33.59
4.62
36.00
4.21
38.41
5.54
43.07
6.33
47.73
7.13
18
24.27
3.44
28.93
4.14
33.59
4.72
36.00
4.36
38.41
5.65
43.07
6.46
47.73
7.27
20
24.27
3.51
28.93
4.22
33.59
4.81
36.00
4.74
38.41
5.76
43.07
6.70
47.73
7.78
21
24.27
3.54
28.93
4.25
33.59
4.86
36.00
5.10
38.41
5.89
43.07
6.94
47.73
8.06
23
24.27
3.60
28.93
4.35
33.59
5.10
36.00
5.53
38.41
6.30
43.07
7.43
47.73
8.65
25
24.27
3.71
28.93
4.62
33.59
5.47
36.00
5.95
38.41
6.73
43.07
7.95
47.73
9.25
27
24.27
3.95
28.93
4.92
33.59
5.83
36.00
6.61
38.41
7.19
43.07
8.49
47.73
9.90
29
24.27
4.21
28.93
5.24
33.59
6.23
36.00
6.79
38.41
7.68
43.07
9.06
47.73
10.59
31
24.27
4.46
28.93
5.57
33.59
6.64
36.00
7.26
38.41
8.19
43.07
9.68
47.73
11.00
33
24.27
4.75
28.93
5.92
33.59
7.08
36.00
8.21
38.41
8.71
43.07
10.32
47.73
11.41
35
24.27
5.03
28.93
6.30
33.59
7.54
36.00
8.48
38.41
9.29
43.07
11.00
47.73
11.83
37
24.27
5.33
28.93
6.68
33.59
8.04
36.00
8.58
38.41
9.89
43.07
11.73
47.73
12.24
39
24.27
5.65
28.93
7.13
33.59
8.56
36.00
8.72
38.41
10.52
43.07
12.49
47.73
12.67
41
24.27
5.78
28.93
7.19
33.59
8.69
36.00
8.86
38.41
10.71
43.07
12.81
47.73
12.89
43
24.27
5.95
28.93
7.25
33.59
8.82
36.00
8.96
38.41
10.86
43.07
12.96
47.73
13.03
45
24.27
6.12
28.93
7.34
33.59
8.99
36.00
9.09
38.41
11.05
43.07
13.10
47.73
13.24
48
24.27
5.32
28.93
6.22
33.59
7.67
36.00
9.28
38.41
9.39
43.07
11.15
47.73
11.31

Midea V5 X VRF Series Specifications

General

Brand	Midea
Model	V5 X VRF Series
Category	Air Conditioner
Language	English
